AMX has an integration with MTR (Microsoft Teams Room application)?

DamianDamian Junior MemberPosts: 4

Hello!
Do you know if AMX has an integration with MTR (Microsoft Teams Room application) to integrate AV Room control into it? Something like the "Extron Control for Microsoft Teams Rooms" capability.
I particularly need to control the room facilities with the touch panel of the MS Teams Native video conferencing equipment (Yealink, Logitech, Poly, etc.)

Answers

  • HARMAN_ChrisHARMAN_Chris Harman Integrated Technologies Group (ITG) Posts: 467

    There is no MTR integration at this time. Extron essentially adds a button to the MTR screen that triggers a page flip over to an HTML5 GUI that is hosted on their external controller. AMX can host an HTML5 panel on the controller today - the trick is getting that pageflip button onto the MTR screen. Do you have the documentation for adding the button to MTR?

  • DamianDamian Junior Member Posts: 4
    edited December 2021

    Hi Chris, I don't have any document to add the button to MTR, it would be very helpful if you can provide it to me!
    Thanks in advance

  • HARMAN_ChrisHARMAN_Chris Harman Integrated Technologies Group (ITG) Posts: 467

    Damian, it is my understanding that each MTR hardware manufacturer partner controls their specific build of MTR and this is where the button is implemented. I do not have this document.

  • JoakimGiskeJoakimGiske AV technician/programmer Posts: 5

    Hi Damian, I have now sendt an request to Yealink for the API-command sheet for the A30-Teams device. So I will post the answer her, if the anwer is good enough. The module on InConcert lacks the most important functions.
    Cheers

  • nicolaunicolau Junior Member Posts: 39

    I am look for more information with regard to this video, that says about integration with AMX and MTR systems controlled by Yealink MTouch II Controller:

    Can someone give more detailed information?

  • HARMAN_icraigieHARMAN_icraigie Technical Trainer II, Harman Professional University Posts: 610

    Keep your eye on the Developer Resources page for updates

    https://developer.amx.com/#!/main

  • nicolaunicolau Junior Member Posts: 39

    @HARMAN_icraigie said:
    Keep your eye on the Developer Resources page for updates

    https://developer.amx.com/#!/main

    I couldn't find anything there searching for "Yealink". Could you help?

  • HARMAN_icraigieHARMAN_icraigie Technical Trainer II, Harman Professional University Posts: 610

    @nicolau said:

    @HARMAN_icraigie said:
    Keep your eye on the Developer Resources page for updates

    https://developer.amx.com/#!/main

    I couldn't find anything there searching for "Yealink". Could you help?

    Not released yet - waiting on Yealink official firmware release

  • HARMAN_icraigieHARMAN_icraigie Technical Trainer II, Harman Professional University Posts: 610

    Not shown in the new releases page yet but has been published and available for download.

    https://developer.amx.com/#!/searchresult?Manufacturer=Yealink

    Note that there will be a revised module published by the end of this week with a new jar, example JSON files and documentation.

    The NetLinx programming side is fairly straightforward - same a as touch panel with regards to buttons events, channel feedback and levels. Customization of the control page (JSON file) and setting up client Authentication and Authorization are a couple of the issues that need to be thoroughly understood from the documentation ( there are 3 guides covering different aspects of the solution in the AXW package).
